Hematology Analyzer Z3

TASK

Design of a 3-part Differential Automated Hematology Analyzer for laboratories with low volume workloads. It is capable of serving medium or large laboratories as a back-up.

Definition of a recognizable Zybio product language
Transfer to the design of the tabletop device

SERVICES

Ergonomic consideration
Derivation from design guidelines
Product design
Product graphics
Colour Concept (CMF)
Continuous supervision of the implementation

Hematology
Z3/Z3 CRP
A new generation 3-diff hematology analyzer

Lyse built-in and compact design

10.4inchTouch screen operation
<20KGNet weight

Sensitive，Easy-to-use，Accurate

Provide a more comprehensive
inspection menu

”0”
carry over
mall Package
R2 Reagent built-in

Support review

Effectively support review

Innovative design
reduces misoperations

Two detection modes

Suction needle
side opening

Save time and worry with one click
